How to Install & Use the Featherweight Accurate Seam Guide

Posted by April Henry on

Singer Featherweight 221 Accurate Seam Guide

This seam guide is designed so that you can easily and accurately piece your quilt blocks.  Whether you prefer a scant or a true quarter inch (1/4") seam (or even beyond), your seams will have consistent seam allowances throughout your quilt or sewing project.  Some people prefer a 1/4" foot attachment and those work very well, too, but other quilters prefer something more fixed and secure to the machine bed.  The smooth acrylic finish of the Featherweight Accurate Seam Guide is safer for the machine surface as well.  It is much better than using adhesive or metal seam guides which often harm the clear coat.

Fashioned after the design of the Singer Featherweight with cute gold decals on a black finish, the Accurate Seam Guide also includes an easy-to-grip thumb screw and washer.  The thumb screw allows you to securely screw down the guide to the machine using just your fingers.  Another nice feature is that our seam guide has a 3/16-inch edge - which is slightly taller than others, allowing you more visibility and ease for your fabric to feed against.

Singer 221 Featherweight Accurate Seam Guide

Now let's learn how to measure and attach your Featherweight Accurate Seam Guide so you can start sewing!

1.)  You will notice the easy-to-grip thumb screw and washer included with the guide.  Slip the screw through the washer, and place it in the slot on the seam guide.  Using one of the holes on the bed of the machine (see arrow below), turn the screw to the right to just get it started in the threads (see next two photos).

Singer 221 Featherweight Accurate Seam Guide

Singer 221 Featherweight Accurate Seam Guide

You can get the screw started, but at this point you want to still be able to slide the guide back and forth.

 Singer 221 Featherweight Accurate Seam Guide

2.)  Next, lower your needle through the needle hole in the throat plate by rotating the handwheel toward you (Sidenote:  Always rotate your handwheel toward you when sewing - never rotate it backwards or away from you)

If your needle is not centered in the needle hole, that's perfectly okay and is often quite normal.  Singer did not always design for this centrality, as they were more concerned about perfect alignment of the needle and hook.  Increasing needle size affects the centrality of the needle anyway, so do not be concerned if your needle is not perfectly centered in the hole.  Just make sure to measure from the needle itself.

Singer 221 Featherweight Accurate Seam Guide

3.)  Once your needle is lowered, use a small ruler to measure for your preferred 1/4" seam.  The needle is lowered in the needle hole and the guide is resting up against it.  I like to use my Creative Grids 1" cutting ruler, but other small rulers would work well, too.  Measure from the needle to the left edge of your Featherweight Accurate Seam Guide.  This is where you can determine whether you prefer a true 1/4" seam or a scant 1/4" seam.  (A scant 1/4" is just a hair less than a true 1/4".)

Singer 221 Featherweight Accurate Seam Guide

4.)  Slide your seam guide into position at the correct measurement and tighten the screw so that your Accurate Seam Guide is secure.  You want it tight so the guide won't shift or move easily.  This style of thumb screw makes it easy to quickly tighten or loosen as required -- or even remove the guide altogether if you need to sew half-square-triangles (HSTs).

Now you can begin piecing!
We hope you enjoy your Featherweight Accurate Seam Guide!

For more helpful hints on proper seam alignment, see the tips further below.

Singer 221 Featherweight Accurate Seam Guide

Singer 221 Featherweight Accurate Seam Guide

HELPFUL HINTS AND TIPS for proper seam alignment:

Tip #1:  Not all Featherweights are the same...  What I mean is - and for those of you with more than one Featherweight in your collection - you've probably noticed there are a few subtle differences or variations in their manufacturing.  For example, some Featherweights have throat plates that are perfectly flush with the machine surface.  Other Featherweights have throat plates that sit up a teensy bit higher than the surface.

Singer 221 Featherweight Accurate Seam Guide

This can be normal and so I will show you a quick remedy.  It's actually one of the reasons we opted to keep our guide the same small, square size as the one Dave McCallum had originally made.  This remedy came from Dave and is so simple, but it works perfectly!

If your machine is one that has a throat plate that sits a tad higher than the machine bed, then this sometimes causes a "fabric-thin" gap towards the front of your guide and the bottom fabric can slip underneath if you're not careful.

Singer 221 Featherweight Accurate Seam Guide

Singer 221 Featherweight Accurate Seam Guide

To remedy this, loosen the thumb screw slightly and simply place the enclosed card* under the Accurate Seam Guide (towards the back end) and rescrew the guide down securely again.  (You may need to remeasure your preferred 1/4" measurement.)

* If you have a clear seam guide then a clear card has been included for you as well.

Singer 221 Featherweight Accurate Seam Guide

Adding this card to the back end will make the front end of your guide (the part that you use to guide your fabric) flush with the machine bed.  It will also prevent your fabric from sliding underneath the guide, keeping your seams aligned and accurate along the left edge.

Singer 221 Featherweight Accurate Seam Guide
You can see here where I am trying to get my fabric to slip under the seam guide after adding the card, but it is now prevented from doing so.  Problem solved!  And I now have the nice thick seam guide edge for my fabric to feed against.  I love it!

Singer 221 Featherweight Accurate Seam Guide

Tip #2:  "What are those measurements for on the front edge?" you may ask.... Quite frankly, like the cute gold decals, they are there for fun but also practicality!  Because the measuring lines are accurate, you can quickly measure and verify your stitched seam allowances right at the machine.

Singer 221 Featherweight Accurate Seam Guide
What's that you see?  Singer Featherweight FABRIC?!  Why, yes -- yes, it is!
Of course The Featherweight Shop has Singer 221 Featherweight Fabric!

Tip #3:  Make a test block to measure for accurate seam allowances.  I cut three strips (see above photo), each one precisely measuring two inches wide (watch that cutting - it can make a difference, too!).  I then stitched a scant 1/4" seam allowance for the two seams to sew the three strips together.  Taking my stitched strips to the ironing board, I pressed my two seams toward the center and then measured them all sewn together.  My sewn strips were a perfect 5 inch finished measurement.  If you find that your finished measurement is slightly narrower than it should be, then try adjusting your seam guide so that it is more of a scant 1/4".

Tip #4:  Pin the opposite direction -- it actually makes matching your seams easier and more accurate.  A quilter friend shared a tip with me one time about using the silk, glass-headed pins.  I love them for seam matching!  They're super fine and don't distort the alignment and I can sew over them with ease.  (Yes, occasionally, they'll bend or kink, but that's the nature of having a sewing life, right? <wink-wink>)

Here's a quick video tutorial where I demonstrate how to do this (I was working on a Great-Granny Square Quilt for Ruthie.)

Well, that covers our newest guide - and if you have any questions, let us know in the comments below.
